Intel Xeon processors represent a broad product line to meet a range of demanding performance and energy efficiency requirements for compute-intensive embedded, storage, and communications applications.
Features |
|
Embedded options available | |
Execute Disable Bit | |
Idle States | |
Maximum number of PCI Express lanes | 40 |
PCI Express slots version | 3.0 |
Scalability | 2S |
Supported instruction sets | AVX 2.0 |
Thermal Design Power (TDP) | 85 W |
Thermal Monitoring Technologies | |
Graphics |
|
On-board graphics adapter | |
Memory |
|
ECC supported by processor | |
Maximum internal memory supported by processor | 768 GB |
Memory bandwidth supported by processor (max) | 51 GB/s |
Memory channels supported by processor | QUAD |
Memory clock speeds supported by processor | 1600 MHz |
Memory types supported by processor | DDR4-SDRAM |
Operational conditions |
|
Tcase | 70.9 °C |
Power |
|
VID Voltage Range | 0.65 - 1.30 V |
Processor |
|
Box | - |
Bus type | QPI |
Component for | server/workstation |
Number of QPI links | 2 |
Processor cache | 15 MB |
Processor cache type | L3 |
Processor cores | 6 |
Processor family | Intel Xeon E5 v3 |
Processor frequency | 1.9 GHz |
Processor front side bus | - MHz |
Processor lithography | 22 nm |
Processor Model | E5-2609V3 |
Processor operating modes | 64-bit |
Processor socket | LGA 2011-v3 |
Processor threads | 6 |
System bus rate | 6.4 GT/s |
Processor special features |
|
Enhanced Intel SpeedStep Technology | |
Intel AES New Instructions | |
Intel Demand Based Switching | |
Intel Flex Memory Access | |
Intel Hyper-Threading Technology | |
Intel Identity Protection Technology | |
Intel Secure Key | |
Intel Trusted Execution Technology | |
Intel TSX-NI | |
Intel Virtualization Technology (VT-x) | |
Intel Virtualization Technology for Directed I/O (VT-d) | |
Intel vPro Technology | |
Intel VT-x with Extended Page Tables (EPT) | |
OS Guard | |
Other features |
|
Compatibility | HP DL180 |
Intel Virtualization Technology | VT-d,VT-x |
