Design |
|
| Colour of product | Black |
| Internal |
|
|
Networking |
|
| Auto MDI/MDI-X |
|
| Converter input interface | 1000Base-T |
| Converter output interface | 1000Base-LX,1000Base-SX |
| Data transfer rate (max) | 2000 Mbit/s |
| Duplex system | Full,Half |
| Ethernet interface type | Gigabit |
| Ethernet LAN data rates | 1000 Mbit/s |
|
Packaging content |
|
| Manual |
|
|
Performance |
|
| Mean time between failures (MTBF) | 65000 hour(s) |
| Wavelength | 850 nm |
|
Ports & interfaces |
|
| Connectivity Technology | Wired |
| DC-in jack |
|
| Ethernet LAN (RJ-45) ports | 1 |
| Fiber optic connector | SC |
| Fiber ports quantity | 1 |
|
Power |
|
| External power adapter |
|
| Output current | 1 A |
| Output Voltage | 12 V |
| Power consumption (typical) | 4 W |
|
Certificates |
|
| Certification | CE, FCC |
| RoHS compliance |
|
|
Management features |
|
| Plug and Play |
|
|
Operational conditions |
|
| Operating relative humidity (H-H) | 10 - 90 |
| Operating temperature (T-T) | 0 - 60 |
| Storage temperature (T-T) | -10 - 70 |
|
Other features |
|
| Dimensions (WxDxH) | 95 x 160 x 20 |
| Full duplex |
|
|
Weight & dimensions |
|
| Package depth | 203 mm |
| Package height | 90 mm |
| Package weight | 700 g |
| Package width | 135 mm |
| Weight | 600 g |
