Intel NUC Core i3-5010U DDR3L 1.35V SO-DIMM Mini Barebone PC - BOXNUC5I3RYK
Quick Find: 922764

SAVE 15%
Intel NUC Core i3-5010U DDR3L 1.35V SO-DIMM Mini Barebone PC
Was: : £314.99     You save: : £48.02

Now   £266.97 Finance Available
click here

  • Form Factor - UCFF
  • Processor - Intel Core i3-5010U 5010U - 2.1 GHz
  • RAM - 0 MB
  • Graphics -
  • Optical Drive - None
  • Operating System - NO OS
  • Warranty - 3 years warranty
More Info...

Intel Next Unit of Computing Kit NUC5i3RYK - Barebone - UCFF - 1 x Core i3 5010U / 2.1 GHz - HD Graphics 5500 - GigE - WLAN : Bluetooth 4.0 LE, 802.11b/g/n/ac

The 4-inch square Intel® NUC NUC5i3RYK takes the powerful capabilities of a desktop system and packages it into a computer that fits in the palm of your hand. This fully scalable system comes with the latest 5th generation Intel® Core™ i3 processor and integrated Intel® HD Graphics with 4K display support. Whether you want a digital jukebox, home hub, or light gaming PC, the Intel NUC NUC5i3RYK gives you the power to play, create, entertain, and inspire. The system is designed to hold a lightning fast and compact M.2 SSD so you can quickly stream music or movie files, and also features consumer infrared and a Mini HDMI* video interface. With Intel® WiDi1 you can connect your monitor without any additional cables and Bluetooth* lets you place wireless speakers where you want—all the features you want in a space-saving, clutter-free design. A replaceable lid gives you plenty of options to create the Intel NUC you want—with amazing style and features. There’s also a high-speed USB 3.0 charging port that lets you easily charge your tablet or smartphone quickly. And for peace of mind you’ll get embedded security that helps keep threats out, user identities and credentials safe, and your data protected.

  • Form Factor - UCFF
  • Processor - Intel Core i3-5010U 5010U - 2.1 GHz
  • RAM - 0 MB
  • Graphics -
  • Optical Drive - None
  • Operating System - NO OS
  • Warranty - 3 years warranty
Back panel I/O ports
USB 3.0 (3.1 Gen 1) Type-A ports quantity 2B 2F + 0
Back-to-BIOS button
Chassis type -
Colour of product Black,Stainless steel
Water cooling system -
Expansion slots
PCI Express configurations M.2 slot with PCIe X4 lanes
PCI Express slots version Gen2
Discrete graphics adapter model
Number of displays supported 3
Number of displays supported by on-board graphics adapter 3
On-board graphics adapter
On-board graphics adapter base frequency 300 MHz
On-board graphics adapter DirectX version 11.2
On-board graphics adapter dynamic frequency (max) 900 MHz
On-board graphics adapter ID 0x1616
On-board graphics adapter model Intel HD Graphics 5500
On-board graphics adapter outputs supported DisplayPort,Embedded DisplayPort (eDP),HDMI
Internal I/O
Number of SATA connectors 2
Number of SATA III connectors 2
Parallel port via internal header
Serial port via internal header
Internal memory - GB
Internal memory type DDR3L-SDRAM
Maximum internal memory 16 GB
Memory channels 2
Memory Clock Speed 1600 MHz
Memory layout (slots x size) - GB
Memory slots 2x SO-DIMM
Supported memory types DDR3L-1333/1600 1.35V SO-DIMM
Bluetooth version 4.0
Cabling technology 10/100/1000Base-T(X)
Ethernet LAN
Ethernet LAN data rates 10,100,1000 Mbit/s
Wi-Fi standards 802.11ac
Optical Drive
Optical drive type
Optical drives quantity -
Audio system HDA
Energy Star certified
Extended Life Program (XLP)
Intel AC'97 technology
Intel Client Initiated Remote Access (CIRA) technology
Intel HD Audio Technology
Intel Quiet System Technology (QST)
Intel Remote PC Assist Technology (RPAT)
Motherboard chipset -
Product Type Mini PC (<= 3L)
Trusted Platform Module (TPM)
Ports & interfaces
Combo headphone/mic port
DC-in jack
DVI port
Ethernet LAN (RJ-45) ports 1
HDMI ports quantity 0
Headphone outputs 0
Microphone in
Mini DisplayPorts quantity 1
Mini HDMI ports quantity 1
S/PDIF out port
USB 2.0 ports quantity 2
USB 3.0 (3.1 Gen 1) Type-A ports quantity 4
VGA (D-Sub) ports quantity 0
Power supply 65 W
Bus type DMI2
Configurable TDP-down frequency 600 MHz
Conflict Free processor
ECC supported by processor
FSB Parity
Maximum internal memory supported by processor 16 GB
Maximum number of PCI Express lanes 12
Memory bandwidth supported by processor (max) 25.6 GB/s
Memory channels supported by processor Dual
Memory clock speeds supported by processor 1333,1600 MHz
Memory types supported by processor DDR3L-SDRAM,LPDDR3-SDRAM
Number of processors installed 1
PCI Express configurations 2x4,4x1
PCI Express slots version 2.0
Processor cache 3 MB
Processor cache type L3
Processor codename Broadwell
Processor cores 2
Processor family Intel Core i3-5xxx
Processor frequency 2.1 GHz
Processor front side bus - MHz
Processor lithography 14 nm
Processor Model i3-5010U
Processor operating modes 32-bit,64-bit
Processor series Intel Core i3-5000 Mobile series
Processor socket Soldered-down BGA
Processor socket BGA1168
Processor threads 4
Stepping F0
System bus rate 5 GT/s
Thermal Design Power (TDP) 15 W
Tjunction 105 °C
Processor special features
CPU configuration (max) 1
Embedded options available
Enhanced Intel SpeedStep Technology
Execute Disable Bit
Graphics & IMC lithography 14 nm
Intel 64
Intel AES New Instructions
Intel Anti-Theft Technology
Intel Clear Video HD Technology
Intel Clear Video Technology
Intel Clear Video Technology for MID
Intel Demand Based Switching
Intel Dual Display Capable Technology
Intel Enhanced Halt State
Intel Fast Memory Access
Intel FDI Technology
Intel Flex Memory Access
Intel Hyper-Threading Technology
Intel Identity Protection Technology
Intel Identity Protection Technology version 1.00
Intel Insider
Intel InTru 3D Technology
Intel My WiFi Technology
Intel Quick Sync Video Technology
Intel Rapid Start Technology -
Intel Rapid Storage Technology
Intel Secure Key
Intel Secure Key Technology version 1.00
Intel Small Business Advantage (SBA)
Intel Small Business Advantage (SBA) version 1.00
Intel Smart Connect Technology -
Intel Smart Response Technology
Intel Smart Response Technology version 1.00
Intel Stable Image Platform Program (SIPP) version 0.00
Intel Trusted Execution Technology
Intel TSX-NI version 0.00
Intel Turbo Boost Technology
Intel Virtualization Technology (VT-x)
Intel Virtualization Technology for Directed I/O (VT-d)
Intel vPro Technology
Intel VT-x with Extended Page Tables (EPT)
Intel Wireless Display (WiDi) Technology
OS Guard
Processor code SR23Z
Processor package size 40 mm
Supported instruction sets AVX 2.0,SSE4.1,SSE4.2
Thermal Monitoring Technologies
Operating system installed
Card reader integrated
Storage media -
Total Storage Capacity - GB
Weight & dimensions
Depth 111 mm
Height 34.5 mm
Weight - g
Width 115 mm
Energy Star certified -
EPEAT compliance -
Other features
Embedded options available
Graphics output Mini-DP 1.2, Mini-HDMI 1.4a
Maximum internal memory 16384 MB
Packaging content
Display included -
Keyboard supplied -
Mouse included -
Processor special features
Intel Fast Memory Access
Intel Flex Memory Access
Technical details
Audio Channels 7.1 digital (mHDMI mDP); L+R+mic (F)
Born on date Q1'15
Built-in WiFi Intel Wireless-AC 7265 + BT 4.0
DC input capable
Form factor UCFF (4" x 4")
Integrated LAN 10/100/1000
Intel Virtualization Technology (VT-x) 1
Intel Virtualization Technology for Directed I/O (VT-d)
Intel visual technologies Intel Clear Video HD,Intel Insider,Intel InTru 3D,Intel Quick Sync Video
Launch date 2015-01-05T00:00:00
Market segment DT
Maximum memory 16 GB
Memory bandwidth (max) 25.6 GB/s
Number of DIMM slots 2
Product name Intel NUC Kit NUC5i3RYK
Product Type 11
Requires a processor with Intel Graphics Technology
Status 4
Thermal Design Power (TDP) 15 W
USB ports quantity 6
USB version 2.0 3.0
